HANDICARE 4000 SIMPLICITY
The Handicare 4000 series stairlift suits most staircases with bends or corners and offers you all the basic functions that you would expect.
HANDICARE 4000 SIMPLICITY
The twin rail stairlift is very similar to our single rail solutions with added durability and a heavier weight capacity.
RAIL IS AVAILABLE IN LIGHT GREY, BROWN OR GUN METAL
HEAVY WEIGHT-BEARING CAPACITY
NEUTRAL SAND COLOURED WIPE CLEAN FLAME RETARDANT FABRIC
ADDED DURABILITY
OPTION OF A POWERED FOOTPLATE
SWIVEL SEAT
Buying a stairlift from Beechfield Stairlifts has never been easier! We have partnered with Flexi-Fi, so you can now spread the cost of your stairlift.
SPECIFICATIONS
Specifications
- Standard swivel radius 720mm
- with short arm option 685mm
- Minimum wall to seat back 96mm
- Seat d epth 385mm
- Minimum folded width to footplate 400mm
- Minimum open width to edge of footplate 689mm
- Armrest width – external 635mm
- Armrest width – internal 480mm
- Seat back height 400mm
- Footplate to seat height 497-579mm
- Minimum footplate height 70mm
- Bottom parking space required at 45° 670mm
- Minimum track intrusion into staircase 116mm
- Standard track intrusion at bottom of stairs 500mm
- Minimum track intrusion at bottom of stairs – reduced lower intrusion 420mm
- Maximum weight limit 115kg/18 stone
- Heavy duty version 137kg/21.5 stone
- Speed 0.12m/sec (approx)
- Maximum staircase angle 56°
Options available:
Safety
- Safety sensors designed to stop the lift if it meets any obstructions
- Emergency stop
- Retractable seat belt
- Key operated switch
- Footrest safety edges
